Intelligent Config PC App Release Notes

Product applicability

The Intelligent Config PC App is used to connect to iNav and iNS APS push buttons and control units:

• iN2/iN3 (all variants)
• iNS2/iNS3 (all variants)
• iDS2/iDS3 (all variants)
• iCCU-C/C2
• iCCU-S/S2

Note: Intelligent Config does not work with iNX/iDX units. These units are only compatible with the Polara FS App available on iOS or Android devices.

Intelligent Config v1.16.03 (2025-01-27)

Includes Firmware: iNav v4.19 / iNS v5.0.3 / iCCU v4.02 / WPC v1.1.0 / WPSE v1.2.0

• Increase performance of firmware update with v5.1.0 and greater.

Intelligent Config v1.16.02 (2024-11-19)

Includes Firmware: iNav v4.19 / iNS v5.0.3 / iCCU v3.100 / WPC v1.0.3 / WPSE v1.1.0

• Add ability to check for updated Help Documents from polara.com
• Added ability to connect to and configure WPSE devices
• Add new live RSSI view to WPC info page while connected to WPSE (Jira WII-1615).
• Modify list of iCCU Ethernet addresses to include search & filtering, new Region/Area field, and ability to set specific passwords for different units
• Allow concurrent editing of iCCU Ethernet list in Intelligent Config app and Polara Updater app.
• Standardize Health Log clearing behavior across all device types
• Standardize the naming of Preemption options
• Add detection of a running Network-Initiated Firmware Update and add Abort command
• Fix issue causing BIU #5-8 not to be selectable when SDLC/BIU mode enabled
• [Fix issue with Ped LED Recall option missing]
• [Updated SDLC Channel Assignment for clarity]
• [Fix issue where feedback is not given to user when selecting Recalibrate & Restart button in Adv. Comm Settings]
• [Fix issue where loading legacy settings config files zeroes out Push Button Config volumes]
• [Add better instructional text upon iNS firmware update failure]

Intelligent Config v1.15.03 (2024-01-24)

Includes Firmware: iNav v4.19 / iNS v5.0.1 / iCCU v3.99 / WPC v1.0.1

• Add requirement for users to view and accept the software license agreement before using the PC App
• Fix issue which caused the Check For Updates page to not allow new firmware or PC App downloads
• Fix possible crash when performing a reset to factory default sounds
• Update with the latest help documents
• [Check for latest SLA from Polara website and redisplay if newer SLA is available]

Intelligent Config v1.15.02 (2023-11-21)

Includes Firmware: iNav v4.18 / iNS v5.0.1 / iCCU v3.98 / WPC v1.0.1

• Improve file transfer speed for certain firmware versions
• Fix crash which can occur when clicking the Connect button on the Ethernet tab
• Prevent window from becoming hidden if monitor configuration has changed

Intelligent Config v1.15.01 (2023-09-29)

Includes Firmware: iNav v4.18 / iNS v5.0.0 / iCCU v3.98 / WPC v1.0.1

• Add compatibility with Wireless Ped Connector (WPC)

Intelligent Config v1.14.06 (2021-07-20)

Includes Firmware: iNav v4.13 / iNS v4.0.14 / iCCU v3.94

• Fix issue with "Check for Updates" page not being able to connect to the server

Intelligent Config v1.14.05 (2021-04-19)

Includes Firmware: iNav v4.13 / iNS v4.0.13 / iCCU v3.93

• Change iDetect Rain Detect feature to default to off
• [Change behavior of iDetect profile selection such that when changing from Profile 0 to Profile 1, the default option for Rain Lockout is ‘Off’ instead of ‘Low’]
• [Fix issue in iDetect screen which occurred if a user loaded the iDetect screen more than once. The Rain Lockout option would always load as ‘Low’ regardless of the actual setting when the iDetect screen was loaded a second time and each subsequent time]

Intelligent Config v1.14.04 (2021-04-01)

Includes Firmware: iNav v4.13 / iNS v4.0.13 / iCCU v3.92

• Add ability to enable ped call logging on iCCU units (v3.91 or greater)
• Add Rain Lockout option to iDetect settings (iNS v4.0.13 or greater)
• Add display of expanded button counts (iNav v4.13/ iNS v4.0.13 or greater)

Intelligent Config v1.14.03 (2020-01-21)

Includes Firmware: iNav v4.12 / iNS v4.0.12 / iCCU v3.91

• Update iDetect Settings screen to allow setting new iDetect Profile One
• Allow new PLC Channel C to be set in Advanced Comm Settings

Intelligent Config v1.14.01 (2020-11-16)

Includes Firmware: iNav v4.11 / iNS v4.0.11 / iCCU v3.90

• Add support for iNS with encrypted BLE connections
• Add support for iDS units and modification of iDetect settings
• Improved program stability

Intelligent Config v1.14.00 (2020-07-02)

Includes Firmware: iNav v4.08 / iNS v4.0.8 / iCCU v3.89

• Add support for new iNS family of products
• Improved reliability of the BLE connection process
• Improved reliability of Firmware Update process
• Add auto-login feature enabling users to add a default password to attempt upon connecting to a unit
• Add Push Confirm Message Vol Min/Max to Settings
• Add ability to set Wireless Sync features on iN2/iNS2 buttons if firmware version is v4.02 or greater.

Intelligent Config v1.13.12 (2019-05-23)

Includes Firmware: iNav v3.207 / iCCU v3.88

• Improve reliability of BLE connection and firmware update in environments with high Bluetooth activity
• Updated manuals
• Updated database of health log entries

Intelligent Config v1.13.11 (2018-11-15)

Includes Firmware: iNav v3.206 / iCCU v3.88

• Add ability to read new health log format
  • Add cancel button when reading health log
  • Add count of health log entries while reading
• Fix issues which could cause a problem when changing to a password of 17 characters in length
• Add the ability to read the current status of the GPIn pins (in the GPIn/Preemption screen)
• Add a display for all device’s settings in one page in the information screen
• Add a a display of the current Interval data being received by the source as well as Load Switch / SDLC connection status
• Add the serial number of the iCCU to the automatically generated filename during health log export
• Add a warning when updating firmware to v3.88 or v3.206 that the health log will be cleared (and recommend exporting)
• Add a new list-view for PBS Status. Users can switch between a graphical view and a list view (which matches iOS/Android displays)
• Add more detailed information to the LED Flash Guide in user manuals screen
• Add the ability to change Load Switch assignments in Advanced Mode of 4-Channel Cabinet Ped Interface settings

Intelligent Config v1.13.09 (2018-08-10)

Includes Firmware: iNav v3.196 / iCCU v3.86

• Add ability to set SNMP options on iCCU units with v3.86 or later firmware
• Add ability to set SNTP options on iCCU units with v3.86 or later firmware
• Add ability to set Advanced DST options on iCCU units with v3.86 or later or iN3 units with v3.205 or later firmware
• Update online software update checking to use TLS v1.2 security
• Add ability to drag/drop audio files onto the app to convert to .ogg
• Fix issue causing Info Message Vol Max values to be beyond acceptable or causing conflicting ranges with Min values
• Fix issues with Audio Upload using script file

Intelligent Config v1.13.08 (2018-03-29)

Includes Firmware: iNav v3.202 / iCCU v3.82

• Changed configuration file extension from .pcf to .inavcfg for better device compatibility.
• Added audio file extraction (iNav v3.199 or greater) in the Audio Update screen
• Added the ability to select the Cuckoo sound as a Clearance Mode Sound and also added the ability to upload a new Cuckoo sound (iNav v3.202 or greater)
• For iN3 devices: Added feature to turn on the Pilot LED during the Don't Walk and Clearance cycles (v3.202 or greater)
• Added an LED Flash Guide in the User Manual screen

Intelligent Config v1.13.07 (2018-02-20)

Includes Firmware: iNav v3.199 / iCCU v3.82

• Fixed the text on some information popup boxes which incorrectly were entitled "Error"
• Updated the bundled versions of firmware

Intelligent Config v1.13.06 (2017-12-04)

Includes Firmware: iNav v3.196 / iCCU v3.80

• Added the following sounds to the Audio Update dropdown selector:
  • Custom Clearance
  • Preemption Msg #1 & #2
  • 2nd Lang Info Msg
  • 2nd Lang Custom Walk
  • 2nd Lang Wait
  • 2nd Lang Name

Intelligent Config v1.13.05 (2017-11-29)

Includes Firmware: iNav v3.196 / iCCU v3.80

• Updated iN2 and iN3 manuals.
• Added Quick-Start guides to the user manual screen. Manuals are selectable via a file menu.
• Additional minor fixes and enhancements.

Intelligent Config v1.13.04 (2017-10-03)

Includes Firmware: iNav v3.195 / iCCU v3.79

• Added ability to enable SDLC/BIU mode which allows ped calls to be transmitted to the traffic controller via SDLC. Note: This requires configuration of the traffic controller and should only be performed by qualified technicians and engineers.

Intelligent Config v1.13.03 (2017-10-10)

Includes Firmware: iNav v3.194 / iCCU v3.78

• Added Advanced Communication Settings screens for iCCU and iN2 units.
• Added additional Information Message configuration setting options.
• Additional minor fixes and enhancements.

Intelligent Config v1.13.02 (2017-07-18)

Includes Firmware: iNav v3.190 / iCCU v3.75

• Changed version number to match closer with iOS version number.
• Improved the Wireless Sync screen to eliminate invalid entries and improve visual mechanics.
• Synchronize maintenance mode status when loading the PBS Configuration Settings screen.
• Improved PBS Parameter Settings help information.
• Increased reliability of iCCU Firmware Update over WiFi.

Intelligent Config v1.00.12 (2017-06-08)

Includes Firmware: iNav v3.187 / iCCU v3.70

• Add a new Cabinet Ped Interface screen to automatically configure channels and Ped Call settings.
• Add a new Advanced Settings screen for additional customization of the channels and Ped Call settings.
• Add information about the connected unit to the health log when exporting.

[v1.00.10] - 2017-04-24

Includes Firmware: iNav v3.179 / iCCU v3.60

• Update the bundled iN2 manual to the latest version (r170424).
• Added Information Message Volume Maximum configuration setting for iNx v3.183 or higher.
• Fixed issue which could cause the program to crash when attempting to connect to a BLE device which is no longer available.

Intelligent Config v1.00.09 (2017-04-20)

Includes Firmware: iNav v3.179 / iCCU v3.60

• Updated the bundled iN2 manual to the latest version (r170410).
• Added a button to reset the iCCU to the iCCU Information page.
• Prevent invalid characters (slash, colon, asterisk, etc...) from being used in the iNx name.
• Disabled menu buttons while firmware update process is busy.

Intelligent Config v1.00.08 (2017-04-10)

Includes Firmware: iNav v3.179 / iCCU v3.60

• Added the ability to upload Second Language files to the Audio Upload Advanced Options menu.
• Added new configuration parameters to settings list: Double Walk, Limit Push Recall, & First Push Only for Extended Push Priority.
• Added help tool-tip popups for all configuration parameters.
• Prevent the computer from going to sleep while the Intelligent Config program is open. This prevents the computer from going to sleep while performing a firmware update which causes the update to fail.
• Added Red LED as a GPIn Function option. This feature turns on the Pilot LED for all iN2 units during Clearance and Don’t Walk cycles to inform pedestrians that a call has already been placed. This is typically used if the intersection is kept in recall for extended periods of time.
• Added iCCU Information screen to display iCCU Serial Number, WiFi SSID, & Firmware Version.
• Added Ped Isolator page to allow momentary ped calls or locked ped calls.
• Added User Manual page to display the iN2 and iN3 manuals. Note: Requires Adobe Acrobat plugin.
• Empty the previously displayed health log data when connecting to a new device.
• Change the iCCU nickname field to display the iCCU SSID.
• Added a Clear All Health Logs function to clear the health logs of all connected iN2 units.
• Fixed an issue which caused the BLE device list to remain visible after a iN-DGL had been disconnected from USB.
• Fixed an issue which could cause a BLE device to appear in the device list more than once.
• Fixed an issue which could cause a delayed response in an error message when failing to connecting to a BLE device.
• Fixed issues with BLE connection timing.
